A312/ A312M TP309S S30908 Stainless Steel Pipe Tube Used In Furnace Material



Stainless Steel Pipe Tube A312/ A312M TP309S S30908 Used in furnace material



Introduction to products:

The corresponding Chinese brand of 309S is 0Cr23Ni13, and the American standard S30908 (American AISI, ASTM) characteristics and uses: corrosion resistance and heat resistance are better than 0Cr19Ni9.
The 309s is a variant of the lower carbon 309 stainless steel for use where welding is required. The lower carbon content minimizes the carbides precipitated in the heat-affected zone near the weld, which can lead to intergranular corrosion (welding erosion) in stainless steel in some environments.



APPLICATIONS :

Use: furnace material.
Widely used in boilers, energy (nuclear power, thermal power, fuel cell), industrial furnaces, incinerators, heating furnaces, chemical, petrochemical and other important fields.



Chemical Composition of 309S(S30908)



  C Si Mn Ni P S Cr Nb
Min 0.04     9     17
Max 0.10 1 2 12 0.045 0.030 19 8xC-1.10





Description for our production range:

Name :Stainless Steel seamless Pipe

Standard :

A213

Material Grade :

S34709

Diameter :OD: 6-830mm
W.T: 0.6mm - 60mm

Length :Up to 13 meter or as customers' request

Tolerance :According to the Standard.

Surface :

Natural Color of annealing & pickling, 180G, 320G, 400G Satin / Hairline

400G, 500G, 600G or 800G Mirror finish

Test :

UT, ET, HT, RT,ect, and others according to the standard,
or as the requests of the customer



our products packing:

A312/ A312M TP309S S30908 Stainless Steel Pipe Tube Used In Furnace Material 0



Tensile Requirements – Stainless Steel 310S/310H:

Tensile Strength (KSI): 75

Yield Strength (KSI): 30





Notes:



10-6·K-1 = 10-6/K

1 Ω·mm²/m = 1 μΩ·m

1 g/cm3 = 1 kg/dm3 = 1000 kg/m3

1 GPa = 1 kN/mm2

1 MPa = 1 N/mm2



other supplement:

1.A999/A999M: Each pipe shall be subjected to the nondestructive electric test or the hydrostatic test, the pipe of test to be used shall be at the option of the mfg, unless otherwise specified in the PO.
2. The Pipe lengths : Unless otherwise agreed upon, all size from NPS 1/8" TO AND INCLUDING nps 8 are available in a length up to 24ft with the permitted range of 15 to 24 ft. Short length are acceptable and the number and min, length shall be agreed upon between mfg and purchaser.
3. The finished pipe shall be reasonably straight and shall have workmanlike finish, Removal of imperfections by grinding is permitted, provided the W.T are not decreased to the less than the permitted in Section 9 of Specification A999/A999M
4. Butt Weld End: According to ANSI B 16.25
5. Pipe Marking: Specified in A999/999M, include "Logo+Standard+SIZE+Heat No.+Lot No.+H.T/E.T/U.T"
6. Packing: Each Pipe end is protected by Plastic cap. Then packed by Anti-rust steel strip, The outside of the bundle is plastic woven bag, or Plastic film.
7. Packing Mark: SIZE + STEEL GRADE+ QTY OF PIECE/WEIGHT/METRE.
8.MTC: BWSS Official Original MTC paper will be supplied for each order.
