Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001
Model Number: 316H
Payment & Shipping Terms
Minimum Order Quantity: MOQ 1Ton
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 7-15 working days after receiving payment
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 Ton/Tons per Month
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industrial And Commercial Applications |
Technique: |
Cold Drawn Or Hot Rolled |
Steel Grade: |
300 Series |
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industrial And Commercial Applications |
Technique: |
Cold Drawn Or Hot Rolled |
Steel Grade: |
300 Series |
General Properties
Alloy 316H (UNS S31609) is a high carbon modification of Alloy 316 developed for use in elevated temperature service. The alloy has higher strength at elevated temperatures and is used for structural and pressure vessel applications at temperatures above 932°F (500°C). The higher carbon content of 316H also delivers higher tensile and yield strength than 316/316L and its austenitic structure provides excellent toughness down to cryogenic temperatures. It is often used in process streams containing chlorides or halides. The alloy resists atmospheric corrosion, as well as, moderately oxidizing and reducing environments. It also resists corrosion in polluted marine conditions. Alloy 316H is non-magnetic in the annealed condition. It cannot be hardened by heat treatment, however the material will harden due to cold working. It can be easily welded and processed by standard shop fabrication practices.
Use
316H.Due to its superior corrosion resistance, 316H stainless steel is ideal for use in marine environments or any situation where exposure to saltwater or other corrosive elements is likely. It’sIt’s also often used in medical equipment due to its resistance to bacterial growth and corrosion-resistance properties. Additionally, due to its strength and durability, it’s commonly used in construction projects such as bridges, buildings, and other infrastructure projects. Finally, its superior malleability makes it perfect for DIY projects like custom kitchen sinks or outdoor furniture.
Physical properties
| Density | Specific Heat |
| 0.285 lbs/in3 8.00 g/cm3 |
0.11 BTU/lb-°F (32 – 212°F) 500 J/kg-°K (0 – 100°C) |
| Electrical Resistivity | Modulus of Elasticity |
| 74 Microhm-cm at 20°C 29.1 Microhm-in at 68°F |
29.0 x 106 psi 200 GPa |
| Melting Range | Thermal Conductivity 212°F (100°C) |
| 2507 – 2552°F 1375 – 1400°C |
8.7 BTU/hr/ft2/ft/°F 15 W/m-°K |
Specification
| Ends | Plain end |
| Production process |
The round steel→Peeling→Heating→Perforation→Acid picking→End preparation→Grinding→Lubricating→Cold-drawn→Degreasing→Annealing→Straightening→Acid picking→Finishing→Testing/inspection→seamless pipe→marking→packing→weighs→weighs→products storage→leaves the plant |
| Delivery time | within 10 -15 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package | Standard export seaworthy package,or as required. |
316H Stainless Steel is composed of molybdenum-bearing austenitic stainless steel developed for elevated-temperature applications. It has excellent corrosion resistance and creep strength. The addition of molybdenum provides greater corrosion resistance against chlorides and other industrial solvents, making it an ideal material for Inconel sheets used to foster a safe and secure environment in construction sites as well as various industrial settings.
| Grade | C | Si | Mn | P | S | Ni | Mo | Cr |
| 316H | 0.04-0.1 | 0.75 | 2 | 0.045 | 0.03 | 10.00-14.00 | 2.0-3.0 | 16.00-18.00 |
Mechanical composition
316H has superior strength and excellent corrosion resistance, making it an ideal choice for all forms of metalworking. It can withstand temperatures up to 1010 degrees Celsius, making it useful for welding and other fabrication needs. Additionally, 316H stainless steel demonstrates durability even in extreme conditions like high-pressure and high-temperature environments. Its hardness makes it ideal for use with machining and grinding, while its formability gives it flexibility when needed. All these attributes make 316H stainless steel a popular choice in industrial settings.
| Yield Strength | Ultimate Tensile | Elongation | Hardness | ||
| .2% Offset | Strength | in 2 in. | |||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % | - |
| 30,000 | 205 | 75,000 | 515 | 40 | 95 Rockwell B |
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
