Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001
Model Number: 317
Payment & Shipping Terms
Minimum Order Quantity: MOQ 1Ton
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 7-15 working days after receiving payment
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 Ton/Tons per Month
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industrial And Commercial Applications |
Technique: |
Cold Drawn Or Hot Rolled |
Steel Grade: |
200 Series,300 Series,400 Series |
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industrial And Commercial Applications |
Technique: |
Cold Drawn Or Hot Rolled |
Steel Grade: |
200 Series,300 Series,400 Series |
Specification
| Ends | Plain end |
| Production process |
The round steel→Peeling→Heating→Perforation→Acid picking→End preparation→Grinding→Lubricating→Cold-drawn→Degreasing→Annealing→Straightening→Acid picking→Finishing→Testing/inspection→seamless pipe→marking→packing→weighs→weighs→products storage→leaves the plant |
| Delivery time | within 45 -60 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package | Standard export seaworthy package,or as required. |
Architecture and Construction
Automotive and Transportation
Medical
Oil and Gas
Food and Drug
317 stainless pipe Chemical Composition
| Grade | C (Max) | Mn (Max) | P (Max) | S (Max) | Si (Max) | Cr | Ni | Mo | Nitrogen (Max) | Cu/ Others |
| 317 | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 18.00 - 20.00 | 11.00 - 14.00 | 3.00 - 4.00 | 0.1 | 0 |
Mechanical composition
| Grade | Tensile | Yield | %Age | Hardness (Max) | |
| Strength Mpa, (Min) | Strength | Elongation | |||
| Mpa, (Min) | in 50mm | ||||
| gauge length min | BHN | Rb | |||
| 317 | 515 | 205 | 35 | 217 | 95 |
Uses
offshore oil rigs
chemical storage tanks
fuel injection systems
aerospace components
kitchen appliances, architectural cladding panels and automobile exhaust systems
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
