Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001
Model Number: tubing
Payment & Shipping Terms
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 30 working days after received your deposit ( Normally according to the order quantity )
Payment Terms: L/C, Western Union, MoneyGram, T/T
Common Materials: |
SUS3004,304,TP304,1.4301 |
Application Field: |
Building Water Supply Pipe, Gas Pipe, Hot And Cold Water Pipe. |
WT: |
SCH5-XXS |
Package: |
Bundle Packing,as Clients Required. |
Out Diameter: |
6mm, 6-3000mm |
Price Terms: |
FOB,CFR,EXW,etc. |
Tolerance: |
±1 |
Common Materials: |
SUS3004,304,TP304,1.4301 |
Application Field: |
Building Water Supply Pipe, Gas Pipe, Hot And Cold Water Pipe. |
WT: |
SCH5-XXS |
Package: |
Bundle Packing,as Clients Required. |
Out Diameter: |
6mm, 6-3000mm |
Price Terms: |
FOB,CFR,EXW,etc. |
Tolerance: |
±1 |
Overview
Stainless steel pipe is an economic cross-section steel, is an important product in the steel industry, SUS3004 stainless steel pipe is widely used in petroleum, chemical, medical, food, light industry, mechanical instrumentation and other industrial transportation pipes and mechanical structural components. There are many kinds of stainless steel pipes, different uses, different technical requirements, and different production methods. There are several classification methods for stainless steel pipes, and when roughly distinguished, they are generally classified according to alloy composition or metallographic organization. According to the composition, it is divided into Cr series and CR-Ni series. Because of the different metallographic structure, the chromium (Cr) series is divided into Martensite series and ferrite series: while the chromium nickel (Cr-Ni) series is divided into austenitic system series and austenite/ferrite series.
Chemical Composition
| Grade | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ |
| SUS3004 | 0.08 | 0.75 | 2 | 0.045 | 0.03 | 8.00-11.00 | 18.00-20.00 |
Mechanical Composition
| Grade | Tensile | Yield | %Age | Hardness (Max) | |
| Strength Mpa, (Min) | Strength | Elongation | |||
| Mpa, (Min) | in 50mm | ||||
| gauge length min | BHN | Rb | |||
| SUS3004 | 515 | 205 | 40 | 201 | 92 |
Specification
SUS3004: Standard Speciicaton for Seamless Feritic and Austentic Alloy -Steel Boiler Superheater,
and Heat-Exchanger Tubes
Advantage
1.Good anti-corrosion performance, effective prevention of a pollution, in line with the national water quality standards.
2. High strength, strong extrusion resistance, resistance to common shock, greatly reducing the possibility of leakage caused by external impact of water pipes.It avoids the destruction of water resources due to seepage
3.Good stability, at -20° C - 350° C
4. The pipe wall is smooth, uniform, no scaling, the path is guaranteed, and the energy consumption is low.
5. Using traditional process connection, safe, reliable, flexible and convenient.
6.Cost-effective
