Product Details
Place of Origin: Wenzhou,China
Brand Name: ZHE HENG
Certification: BV, PED, ISO9001
Model Number: JIS SUS316 ,ASME S31600
Payment & Shipping Terms
Minimum Order Quantity: 500 kg
Price: $1000-4200/Ton
Packaging Details: As to clients' requirements,Wooden Cases,Bundle Packin,Waterproof Paper Covered
Delivery Time: 30-45 work days
Payment Terms: L/C, T/T, D/P, D/A
Supply Ability: 1000+
Term Name: |
Stainless Steel Square Pipe |
Material Grade: |
JIS SUS316 ,ASME S31600 |
Shape: |
Rounde Pipe,Square Pipe,Rectangular Pipe |
Technique: |
Hot Rolled,Pickling |
Length: |
2000mm Or 15000mm |
Size: |
As Per Requirement |
Welding Line Type: |
Seamless,Welded |
Packing: |
As To Clients' Requirements,Waterproof Paper Covered |
Term Name: |
Stainless Steel Square Pipe |
Material Grade: |
JIS SUS316 ,ASME S31600 |
Shape: |
Rounde Pipe,Square Pipe,Rectangular Pipe |
Technique: |
Hot Rolled,Pickling |
Length: |
2000mm Or 15000mm |
Size: |
As Per Requirement |
Welding Line Type: |
Seamless,Welded |
Packing: |
As To Clients' Requirements,Waterproof Paper Covered |
Overview:
JIS SUS316 stainless steel plasticity, toughness, cold change, welding process performance is good, JIS SUS316 high temperature strength, JIS SUS316L high temperature performance is slightly worse, but corrosion resistance is better than JIS SUS316, due to low carbon content and containing 2%-3% molybdenum, The corrosion resistance of reducing salt and various inorganic acids and organic acids, bases and salts is improved, and the high temperature strength is also improved.
Specification:
Approximate Comparative Table | |||||||
ASTM/ASME | ISO | USA | JAPAN | BRITAIN | GERMANY | CNS | |
UNS No. | AISI | JIS | BS | WERKSTOFF DIN | |||
S30400 | 11 | 304 | SUS304 | 304S31 | 1.4301 | X5CrNi1810 | 304 |
S30403 | 10 | 304L | SUS304L | 304S11 | 1.4306 | X2CrNi1911 | 304L |
Outside Diameter | OD 0.28-1219mm |
Thickness | 0.08-100mm |
Seamless Stainless Steel Pipes | 1/8“NB to 32“NB IN |
Production Process | Cold Drawn,Bright Anneal.etc |
Type | Seamless,welded |
Surface | Pickling,Bright; |
Price Item | EXW,FOB,CNF,CIF etc |
Ends: | Beveled or plain end, square cut, burr free |
Stainless Steel Seamless Pipe Chemical Component:
Chemical Composition about stainless steel pipe | |||||||
Grade | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ |
JIS SUS316 | 0.08 | 1 | 2 | 0.045 | 0.03 | 10.00-14.00 | 16.00-18.00 |
JIS SUS316L | 0.035 | 0.75 | 2 | 0.045 | 0.03 | 10.00-15.00 | 16.00-18.00 |
Application
Pulp and paper equipment Heat exchangers, dyeing equipment, pipes, materials for the exterior of buildings in coastal areas, etc.
Mechanical Properties:
Grade | Tensile | Yield | %Age | Hardness (Max) | |
Strength Mpa, (Min) | Strength | Elongation | |||
Mpa, (Min) | in 50mm | ||||
gauge length min | BHN | Rb | |||
301 | 515 | 205 | 40 | 217 | 95 |
304 | 515 | 205 | 40 | 201 | 92 |
304L | 485 | 170 | 40 | 201 | 92 |
310S | 515 | 205 | 40 | 217 | 95 |
316 | 515 | 205 | 40 | 217 | 95 |
316L | 485 | 170 | 40 | 217 | 95 |
317 | 515 | 205 | 35 | 217 | 95 |
317L | 515 | 205 | 40 | 217 | 95 |
321 | 515 | 205 | 40 | 217 | 95 |
347 | 515 | 205 | 40 | 201 | 92 |
409 | 380 | 170 | 20 | 179 | 88 |
409M | 430 | 275 | 20 | 187 | 90 |
410S | 415 | 205 | 22 | 183 | 89 |
410 | 450 | 205 | 20 | 217 | 89 |
420 | 700( max ) | 0 | 15 | 217 | 95 |
430 | 450 | 205 | 22 | 183 | 89 |
JSL AUS | 515 | 205 | 40 | 217 | 95 |
JS- 203 | 515 | 205 | 40 | 217 | 95 |
301M | 515 | 205 | 40 | 217 | 95 |
FAQ:
Q: Are you a manufacturer or merely a trader?
A: We are group of companies and owned manufacturer bases and trading company. We specialized in special steel which include alloy structural steel and carbon steel and stainless steel, etc. All material are with high quality and competitive price.
Q: How do you guarantee the quality of your product?
A: Firstly, we can provide the certificates from the third party, such as TUV, CE, if you need. Secondly, we have a complete set of inspection system and every process is checked by QC. Quality is the lifeline of enterprise survival.
Q: Delivery time?
A: We have ready stock for most of material grades in our warehouse. If the material don't have stock, the delivery lead time is about 5-30 days after receiving your prepayment or firm order.
Q: What is the payment term?
A: T/T or L/C.
Q: Can you provide a sample for our testing before confirm the order?
A: Yes. We can provide sample to you for approval before you place an order to us. Free sample is available if we have stock.
Q: Can we visit your company and factory?
A: Yes, warmly welcome! We can book the hotel for you before you come to China and arrange our driver to our airport to pick you up when you come.
