Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001
Model Number: coil tubing
Payment & Shipping Terms
Minimum Order Quantity: MOQ500kg
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 7-15 working days after receiving payment
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 Ton/Tons per Month
Port: |
Ningbo |
OD: |
0.5-20mm |
Section Shape: |
Round |
Package: |
Seaworthy Standard Package |
Price Terms: |
FOB,CIF,CFR,EXW |
Technique: |
Hot Rolled/Cold Rolled |
Thickness: |
0.1-2.0mm |
Standard: |
ASTM (ASME) SA / A312 /A213 /A269 ,DIN,JIS,EN |
Surface: |
BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
Port: |
Ningbo |
OD: |
0.5-20mm |
Section Shape: |
Round |
Package: |
Seaworthy Standard Package |
Price Terms: |
FOB,CIF,CFR,EXW |
Technique: |
Hot Rolled/Cold Rolled |
Thickness: |
0.1-2.0mm |
Standard: |
ASTM (ASME) SA / A312 /A213 /A269 ,DIN,JIS,EN |
Surface: |
BA/2B/NO.1/NO.3/NO.4/8K/HL/2D/1D |
Feature
Stainless steel coil is resistant to high temperature steam, impact corrosion and ammonia corrosion. Anti-scaling, not easy to stain, anti-oxidation corrosion; Long service life, reduce maintenance time, save costs; Good tube loading process, direct tube change, safe and reliable; The wall is uniform and the wall thickness is only 50-70% of that of copper tube, and the overall thermal conductivity is better than that of copper tube. It is the ideal heat exchange product for the transformation of old units and the manufacture of new equipment. It can be widely used in petrochemical, electric power, nuclear industry, medicine, food and other industries.
Application
Industrial stainless steel coil: heat exchanger, boiler, petroleum, chemical industry, chemical fertilizer, chemical fiber, pharmaceutical, nuclear power, etc
Stainless steel coils for fluids: beverages, beer, milk, water supply systems, medical equipment, etc
Stainless steel coil for mechanical structure: printing and dyeing, printing, textile machinery, medical equipment, kitchen equipment, automobile and ship parts, construction and decoration.
Chemical Composition
| Grade | C | Mn | P | S | Si | Cr | Ni | Mo |
| Carbon | Manganese | Phosphorous | Sulfur | Silicon | Chromium | Nickel | ||
| 304 | 0.080 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.0–20.0 | 8.0–11.0 | |
| 304L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 18.0–20.0 | 8.0–12.0 | |
| 316L | 0.030 max | 2.00 max | 0.045 max | 0.030 max | 1.00 max | 16.0–18.0 | 10.0–18.0 | 2.00–3.00 |
Mechanical Properties
| Yield Strength: | 30 ksi min |
| Tensile Strength: | 75 ksi min |
| Elongation (min 2"): | 35% |
| Hardness (Rockwell B Scale): | 90 HRB max |
Materials available
| American standard | Austenitic Steel | |||||||
| TP304,TP304L,TP304H,TP304N,TP310S,TP316,TP316L,TP316Ti,TP316H,TP317,TP317L,TP321,TP321H.TP347.TP347H.904L... | ||||||||
| Duplex Steel | ||||||||
| S32101,S32205,S31803,S32304,S32750,S32760 | ||||||||
| Others | ||||||||
| TP405.TP409.TP410,TP430.TP439.. | ||||||||
| Europen standard | 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571,1.4438,1.4841,1.4845,1.4539,1.4162,1.4462,1.4362,1.4410.1.4501 | |||||||
Test
Precision bending Smooth bends Surface roughness Ra < 0.5 μm Standard tolerance: ASTM A269, or D4/T4 Strength – Tensile, Burst Hardness – Rockwell, Micro Soundness – Eddy Current, Ultrasonic Leak & Strength – Hydrostatic Leak – Air Under Water Bend Testing – Reverse Bending, Flattening, Reverse Flattening, Flange Dimensional – OD, Wall, Straightness Metallurgical – Grain Size, Sensitization, Corrosion, Phase Balance/Intermetallic, Metallographic
Package
The normal package is Plastic bags with each pipe,after tie in the buddle put the pipes into wooden box if the customer need. We can also packing according to the customer required.
