Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001
Model Number: TP304LN
Payment & Shipping Terms
Minimum Order Quantity: MOQ500kg
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 7-15 working days after receiving payment
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 Ton/Tons per Month
Port: |
Ningbo |
OD: |
Φ6--630mm |
Section Shape: |
Round |
Package: |
Seaworthy Standard Package |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1-12m |
Technique: |
Hot Rolling |
Wall Thickness: |
1-40mm |
Port: |
Ningbo |
OD: |
Φ6--630mm |
Section Shape: |
Round |
Package: |
Seaworthy Standard Package |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1-12m |
Technique: |
Hot Rolling |
Wall Thickness: |
1-40mm |
Overview
304LN is a low carbon, low nitrogen stainless steel with good high temperature strength and corrosion resistance, which is often used in high temperature equipment and pipelines. 304LN has good low temperature toughness and low temperature corrosion resistance in low temperature applications such as refrigeration equipment and low temperature engineering.
Characteristic
1.Good corrosion resistance: 304LN stainless steel has excellent corrosion resistance, performs well in acidic and alkaline environments, and is suitable for manufacturing equipment and parts in chemical, Marine engineering, food processing and other fields.
2.Good machinability: 304LN stainless steel has good machinability, easy to work cold and hot, and can manufacture a variety of complex parts and equipment.
3.Good weldability: 304LN stainless steel has good weldability and can be welded by TIG, MIG and other methods.
Application
Heat exchangers
Chemical industry
Food industry
Petroleum industry
Fabrication industry
Nuclear industry
304LN Stainless Pipe Chemical Composition
304LN is an austenitic alloy made up of chromium, nickel, manganese, silicon, phosphorus, sulfur and nitrogen. It has a low carbon content compared to other grades of stainless steel, which makes it ideal for use in cryogenic applications or for welding components exposed to corrosive environments.
| Grade | C | Si | Mn | P | S | Ni | N | Cr | Fe |
| 304LN | 0.03 | 1 | 2 | 0.045 | 0.03 | 8.00-12.00 | 0.1-0.16 | 18.00-20.00 | Remainder |
Mechanical Properties Stainless Steel 304LN
The mechanical properties of grade 304LN are similar to those of other austenitic stainless steels like Type 316. Its tensile strength ranges between 485MPa (70ksi) and 650MPa (93ksi), while its yield strength can range anywhere between 175MPa (25ksi) and 345MPa (50ksi). Its elongation levels are usually around 40% when tested at room temperature but can go up if the testing environment is hot enough or if the part being tested has undergone heat treatment. Furthermore, its thermal expansion coefficient is 13 x 10-6/K which makes it suitable for use in high-temperature applications such as boilers or exhaust systems.
| Properties | Metric | Imperial |
| Tensile Strength | 515 MPa | 74694 psi |
| Yield strength | 205 MPa | 29732 psi |
| Elogation at break(in 50mm) | 40% | 40% |
| Hardness,Rockwell B | 95 | 95 |
| Hardness,Brinell | 217 | 217 |
Physical Properties
| Tensile strength | Tensile strength | σb/MPa |
| Yield Strength | 23 | σ 0.2 ≥/MPa |
| Elongation | 65 | δ5≥ (%) |
| ψ | - | ψ≥ (%) |
| Akv | - | Akv≥/J |
| HBS | 123-321 | - |
| HRC | 30 | - |
Product Testing
Hydrostatic test
Flaw detection test
Lab test
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
