Product Details
Place of Origin: CHINA
Brand Name: zheheng
Certification: ISO9001 PED
Model Number: 19mm
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: In bundles with waterproof material,or wooden crate packing
Delivery Time: 30 DAYS
Payment Terms: L/C, T/T, D/A, D/P
Supply Ability: 50TONS/30DAYS
Material: |
317 / 347 / 347H |
Standard: |
ASTM A269/ A213 |
Type: |
Seamless |
Technique: |
Cold Drawing |
Product Name: |
317 / 347 / 347H Seamless Stainless Steel Tube |
Surface: |
Polished,annealed, |
Material: |
317 / 347 / 347H |
Standard: |
ASTM A269/ A213 |
Type: |
Seamless |
Technique: |
Cold Drawing |
Product Name: |
317 / 347 / 347H Seamless Stainless Steel Tube |
Surface: |
Polished,annealed, |
ASTM A269/ A213 317 / 347 / 347H seamless stainless steel U bend heat exchanger tube for oil industry
317 / 347 / 347H U bend tubes manufacturer, 317 / 347 / 347H stainless steel U shaped tubes exporter,ASTM a213 317 / 347 / 347H u bend tubes stockholder ,317 / 347 / 347H stainless steel heat exchanger tubes for heat exchanger tube supplier in china
it is widely used in light industry,heavy industry,daily necessities and the decoration industry.my company long-term supply ASTM A269/ A213 317 / 347 / 347H seamless stainless steel U bend heat exchanger tube for oil industry, products including:stainless steel sheet,stainless steel coil and stainless steel 317 / 347 / 347H U bending tube. stainless steel u tube for heat exchanger tubes for oil industry
Process :
1 . We use Cold Drawn techonology to produce U bend tube
2 . U bend tubes produce will accordance to customer's drawings
3 . To avoid oxidation , inert gas (Argon) is passed through tubes ID at the required flow rate
4 . The radius is checked for its OD and wall thinning with the recommended specification
5 . We'll choose three different position or as customer's require to make sure tubes quality . We'll do physical properties and micro-structure test
6 . Visual inspection for waviness and cracks is done with Dye Penetrant Test
7 . Each tube is then hydro tested at the recommended pressure to check for leakage
Production details description:
| Standard | ASTM A554/EN10296-2 |
| Single slot round tube |
38.1 (15x15) ; 42.4 (24x24) ; 48.3 (27x30) 50.8 (15x15) ;50.8(20x20) ; 63(20x20) ; 63 (25x25); 76(25x25) |
| Single slot square slot tube | 32x32 (15x5);38x38(15x15); 40x40(20x20);40x40(15x15);50x50(20x20);50x50(15x15) |
| Single slot rectanguler tube | 38x25(20x15); 50x25(15x15); 50x25(25x25) |
| Thickness | 0.6mm-3mm |
| Thickness Tolerance | +/-10% |
| Length Tolerance | +/-8mm |
| Outside Diameter Tolerance | According to ASTM A554 standard |
| Application | Handrail system, furniture,display shelf,sanitary wares,machinery equipment, automobile |
| Packaging | Each Tube packed by plastic bag individully and then packed by hollow plate and weaving bag. |
|
Production Range: |
|
| Austenitic Steel: | TP304,TP304L,TP304H,TP304N, TP310S,TP316,TP316L,TP316Ti,TP316H, TP317,TP317L, TP321, TP321H,TP347, TP347H,904L… |
| Duplex Steel : | S32101,S32205,S31803,S32304,S32750, S32760 Others:TP405,TP409, TP410, TP430, TP439 ... |
| Russia Standard | 08Х17Т,08Х13,12Х13,12Х17,15Х25Т,04Х18Н10,08Х20Н14С2, 08Х18Н12Б, 10Х17Н13М2Т,10Х23Н18,08Х18Н10,08Х18Н10Т, 08Х18Н12Т,08Х17Н15М3Т, 12Х18Н10Т,12Х18Н12Т,12Х18Н9, 17Х18Н9, 08Х22Н6Т, |
| European Standard | 1.4301,1.4307,1.4948,1.4541,1.4878,1.4550,1.4401,1.4404,1.4571, 1.4438,1.4841,1.4845,1.4539,1.4162, 1.4462, 1.4362, 1.4410, 1.4501 |
Heat Treatment Assurance
A full-automatic natural gas furnace with 24 meters in length.The real temperature tolerance could be within 10℃.
Standard Specification:
1, A312/A312 M Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
2, A213/A213 MSeamless Ferritic and Austenitic Alloy-Steel Boiler,Superheater, and Heat-Exchanger Tubes
3, A269 Seamless and Welded Austenitic Stainless Steel Tubing for General Service
4, A270 Seamless and Welded Austenitic Stainless Steel Sanitary Tubing
5, A 249/A 249M Welded Austenitic Steel Boiler, Superheater, Heat-Exchanger, and Condenser Tubes
6, A 358/A 358M Electric-Fusion-Welded Austenitic Chromium-Nickel Alloy Steel Pipe for High-Temperature Service
7, A 409/A 409M,Welded Large Diameter Austenitic Steel Pipe for Corrosive or High-Temperature Service
8, A 554 Welded Stainless Steel Mechanical Tubing
