Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001
Model Number: TP317
Payment & Shipping Terms
Minimum Order Quantity: MOQ 1Ton
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 7-15 working days after receiving payment
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 Ton/Tons per Month
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industrial And Commercial Applications |
Technique: |
Cold Drawn Or Hot Rolled |
Steel Grade: |
200 Series,300 Series,400 Series |
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industrial And Commercial Applications |
Technique: |
Cold Drawn Or Hot Rolled |
Steel Grade: |
200 Series,300 Series,400 Series |
Trait
Good corrosion resistance: the main alloying elements of 317 stainless steel are chromium, nickel and molybdenum, which makes it have excellent corrosion resistance, especially suitable for strong acid, strong alkali and high temperature environment.
Excellent mechanical properties: 317 stainless steel has a high tensile strength and yield strength,elongation is also relatively high, but also has a high hardness and impact toughness, can still maintain stable performance in high temperature environment.
Easy to process and weld: 317 stainless steel can be processed and deformed by a variety of methods, such as cold working, hot working, deep drawing, etc.
High temperature strength: 317 stainless steel can still maintain high strength and stable performance in high temperature environment, which makes it widely used in high temperature field.
Specification
| Ends | Plain end |
| Production process |
The round steel→Peeling→Heating→Perforation→Acid picking→End preparation→Grinding→Lubricating→Cold-drawn→Degreasing→Annealing→Straightening→Acid picking→Finishing→Testing/inspection→seamless pipe→marking→packing→weighs→weighs→products storage→leaves the plant |
| Delivery time | within 45 -60 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package | Standard export seaworthy package,or as required. |
Architecture and Construction
Automotive and Transportation
Medical
Oil and Gas
Food and Drug
TP317 stainless pipe Chemical Composition
| Grade | C (Max) | Mn (Max) | P (Max) | S (Max) | Si (Max) | Cr | Ni | Mo | Nitrogen (Max) | Cu/ Others |
| TP317 | 0.08 | 2 | 0.045 | 0.03 | 0.75 | 18.00 - 20.00 | 11.00 - 14.00 | 3.00 - 4.00 | 0.1 | 0 |
Mechanical composition
| Grade | TensileStrength Mpa, (Min | Yield Strength Mpa, (Min) | %Age Elongation in 50mm gauge length min | Hardness (Max) | |
| BHN | Rb | ||||
| TP317 | 515 | 205 | 35 | 217 | 95 |
Physical Properties
| Thermal Conductivity | 14.6 | W.m -1.°K-1 |
| Density | 7.99 | g/cm3 |
| Specific Heat (0 To 100°C) | 500 | J.kg-1.°K-1 |
| Thermal Expansion | 16.5 | mm/m/°C |
| Modulus Elasticity | 193 | GPa |
| Electrical Resistivity | 7.4 | μohm/cm |
Uses
Offshore oil rigs
Chemical storage tanks
Fuel injection systems
Aerospace components
Kitchen appliances,architectural cladding panels and automobile exhaust systems
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
