|Standard:||ASME B16.9||Packing:||Wooden Case,|
WP321 4 way seamless BW stainless steel pipe reduce cross ASME B16.9 connector
zheheng steel professional produce all kinds of pipe fittings ,like WP321 4 way seamless BW stainless steel pipe reduce cross ASME B16.9 connector
Concentric Reducer can be used in petroleum, chemical, metallurgical, electricity, machinery, aviation, shipbuilding, and other channels to connect.
1, when the flow of fluid in the pipeline has changed, such as increase or decrease, the flow rate is not required to change, the use of different diameter pipe.
2, in the pump inlet, in order to prevent cavitation, need to use different diameter pipe.
3, and instruments, such as flow meter, the valve of the joints, in order to cooperate with the instrument, but also need to use different diameter pipe.
Pressure Rating Designation
Class, followed by a dimensionless number, is the
designation for pressure-temperature ratings. Standard-
ized designations for flanges per ASME B16.5 referenced
in this Standard are Classes 150, 300, 600, 900, 1500,
Basis of Ratings
The allowable pressure ratings for fittings designed
in accordance with this Standard may be calculated as
for straight seamless pipe of equivalent material (as
shown by comparison of composition and mechanical
properties in the respective material specifications) in accordance with the rules established in the applicable
sections of ASME B31, Code for Pressure Piping. For
the calculation, applicable data for the pipe size, wall
thickness, and material that is equivalent to that of the
fitting shall be used. Pipe size, wan thickness (or sched-
ule number), and material identity on the fittings are in
lieu of pressure rating markings.
stainless steel pipe reduce cross description:
|Products Name||WP321 4 way seamless BW stainless steel pipe reduce cross ASME B16.9 connector|
|Pipe Standard||En 10312:2002; ASTM A688/A688M, ASTM A312, GB/T12771-2008|
|Pipe fitting Standard||EN13480-1:2012; EN13480:2012+A1:2013+A2:2016|
|Steel Material||TP304(SS304), TP304L(SS304L), TP316(SS316), TP316L(SS316L),|
|Size||1/2- 8, DN15 - DN200, according customer's requirements|
|Treatment Conditions||Solution Annealing|
|Connection End||Welding,Annular Compression and Adhesive Connecton|
|Application||Used in pharmacy, beer, food, dairy, beverage, cosmetic, chemical industry|
