Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001
Model Number: SUS316L
Payment & Shipping Terms
Minimum Order Quantity: MOQ 1Ton
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 7-15 working days after receiving payment
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 Ton/Tons per Month
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industry |
Technique: |
Cold Drawn Or Hot Rolled |
Seamless/Welded: |
Welded |
Thickness: |
1mm-150mm(SCH10-XXS) Or As Required |
OD: |
6mm-2500mm (3/8"-100") Or As Required |
Section Shape: |
Round,Square,rectangular |
Surface Finish: |
Polishing, Hair Line,Pickling |
Price Terms: |
FOB,CIF,CFR,EXW |
Length: |
1000-12000mm |
Usage: |
Industry |
Technique: |
Cold Drawn Or Hot Rolled |
Seamless/Welded: |
Welded |
Specification
| Ends | Plain end |
| Standard | JIS DIN ASTM ASME |
| Delivery time | within 45 -60 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| Package | Standard export seaworthy package,or as required. |
Common Industries
Architecture and Construction
Automotive and Transportation
Medical
Oil and GasFood and Drug
SUS316L stainless pipe Chemical Composition
| Mo | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr |
| 2.00-3.00 | 0.03 | 0.75 | 2 | 0.045 | 0.03 | 14.00 | 16.00-18.00 |
Mechanical Composition
| Temper | Annealed | Cold worked (approx. 20%) | |||
| Material:SUS316L | |||||
| Tensile Rm | 70 | ksi (min) | 102-131 | ksi (min) | |
| Tensile Rm | 485 | MPa (min) | 700-900 | mpa (min) | |
| R.p. 0.2% Yield | 27 | ksi (min) | 73-102 | ksi (min) | |
| R.p. 0.2% Yield | 182 | MPa (min) | 500-700 | mpa (min) | |
| Elongation (2” or 4D gl) | 35 | % (min) | 40 | % (min | |
Product Testing
Coating Thk Test
Geometry inspection
Ultrasonic Inspection
Nondestructive Testing
Hydrostatic Testing
Package Process
1.with plastic cap to protect both ends
2.weaving bag wrapped outside the pipe
3.then pack into wooden case.
