Product Details
Place of Origin: Wenzhou,China
Brand Name: Zheheng
Certification: ISO9001,ISO14001, TS16949
Model Number: TP321
Payment & Shipping Terms
Minimum Order Quantity: MOQ 1Ton
Packaging Details: In wooded cases or pallets,or as for clients requirement
Delivery Time: 7-15 working days after receiving payment
Payment Terms: L/C, D/P, T/T, Western Union
Supply Ability: 1000 Ton/Tons per Month
Thickness: |
SCH10-XXS Or As Required |
Size: |
Seamless 1/2" To 24" Welded 1/2" To 48" |
Connection: |
Butt Weld |
Price Terms: |
FOB,CIF,CFR,EXW |
Application Fields: |
Petroleum, Chemical, Machinery, Electric Power, Shipbuilding, Papermaking |
Technique: |
Casting |
Overall Length: |
12 In |
Standards: |
ASTM A403; ASTM A960; ASTM B16.9; MSS SP-43 |
Degree: |
30, 45, 60, 90, 180 Degree |
Shape: |
Equal |
Equipment: |
Pushing Machine,Beveling Machine,Sand Blasting Machine |
Thickness: |
SCH10-XXS Or As Required |
Size: |
Seamless 1/2" To 24" Welded 1/2" To 48" |
Connection: |
Butt Weld |
Price Terms: |
FOB,CIF,CFR,EXW |
Application Fields: |
Petroleum, Chemical, Machinery, Electric Power, Shipbuilding, Papermaking |
Technique: |
Casting |
Overall Length: |
12 In |
Standards: |
ASTM A403; ASTM A960; ASTM B16.9; MSS SP-43 |
Degree: |
30, 45, 60, 90, 180 Degree |
Shape: |
Equal |
Equipment: |
Pushing Machine,Beveling Machine,Sand Blasting Machine |
Specification
| Make process |
Cut the raw material pipe→ Ash loading process→ Suppress →Annealing treatment →Pickling →Polishing→ Rolling sand processing →Do one more pickling→ Bevel end machining |
| Delivery time | within 45 -60 days. |
| Payment Terms | 40% prepayment Balance before lodaing. |
| Shipping Terms | FOB NINGBO, after the inspection of goods at supplier's warehouse |
| End | Plain end |
| Grade | C ≤ | Si ≤ | Mn ≤ | P ≤ | S ≤ | Ni ≤ | Cr ≤ |
| TP321 | 0.04-0.10 | 0.75 | 2 | 0.045 | 0.03 | 9.00-13.00 | 17.00-20.00 |
Mechanical Composition
| Grade | Tensile | Yield | %Age | Hardness (Max) | |
| Strength Mpa, (Min) | Strength | Elongation | |||
| Mpa, (Min) | in 50mm | ||||
| gauge length min | BHN | Rb | |||
| TP321 | 515 | 205 | 40 | 217 | 95 |
Product Testing
Component analysis
penetrating test
impact test
Package Process
Inside:Plastic film packaging.
