Product Details:
Payment & Shipping Terms:
|
| Material: | P11 Seamless Steel Pipe | Standard: | Astm A335 |
|---|---|---|---|
| Type: | Seamless | Technique: | Cold Drawing |
| OD: | 2 Inch | WT: | 2.77MM |
| High Light: | seamless alloy steel pipe,stainless steel metal pipe |
||
Astm a335 p11 seamless steel pipe 2 inch seamless pipe with black painted
We zheheng steel is one of exporter ,manufacturer ,stockist .supply of ASTM A335 p11 seamless alloy pipe,p11 seamless pipe p11 alloy pipe, p11 seamless alloy steel pipe,A335 p11 seamless alloy steel pipe exporter,p11 ss seamless alloy steel pipe supplier ,according to standard ASME SA210,ASME SA213,ASTM SA335, ASTMA335/A335m,ASTMA213/A213m,DIN 17175
description for P11 seamless alloy pipe:
Item:Cold Rolled / Cold Drawn alloy steel seamless pipe
Standard:
JISG3467-88,JISG3458-88,GB3087,GB6479-2000,GB9948-2006, GB5310-95,GB9948-88,ASME SA210,ASME SA213,ASTM SA335, ASTMA335/A335m,ASTMA213/A213m,DIN 17175
Model No.:12Cr1MoV,(10CrMo910),T91,P91,P9,T9,Cr5Mo,15CrMo,P11,P12,13CrMo44,25CrMo,30CrMo,40CrMo,12CrMo,X12CrMo91,12Cr2Mo
Surface:black painted,PE coated,galvanized
Length:6m,5.8m,11.8m,12m, or as required
Wall Thickness:1-120mm Outer
Diameter :6-1200mm
Other complemetary:
|
Trade terms
|
Payment terms
|
T/T,L/C,western union
|
|
|
Price terms
|
FOB,CIF,CFR,Ex-work,CNF
|
|
Package
|
Standard export seaworthy package or as required.
|
|
|
Delivery time
|
Prompt delivery or as the order quantity.
|
|
|
Export to
|
Alloy steel pipe applies to petroleum,chemical industry, electric power, boiler, high temperature resistant, low temperature resistant,corrosion resistant seamless steel pipe used.Alloy steel pipealso can made according to the customer.
|
|
|
Container size
|
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM |
|
|
Contact
|
If you have any question,please feel free to contact me.
|
|
zheheng steel Chemical assurance
1. Each lot of raw materials will be tested by spectrometer before put in storage.
2. 100%PMI the mother pipe to ensure we put right material.
2. 100%PMI the finished pipe again to ensure we produced right grade
| Grade | C | Si | Mn | P | S | Cr | Mo |
| P11 | 0.05-0.15 | 0.5-1.0 | 0.3-0.6 | Max.0.025 | Max.0.025 | 1.0-1.5 | 0.44-0.65 |
| Mechanical properties | |||||||
| Grade | Yield point (Mpa) | Tensile strength (Mpa) | Elongation(%) | Impact value(J) | |||
| P11 | ≥205 | ≥415 | See table | ≥35 |
Materials and Manufacture
1 Pipe may be either hot finished or cold drawn with the finishing treatment as required in
2 Grade P2 and P12—The steel shall be made by coarsegrain melting practice. Specific limits, if any, on grain size ordeoxidation practice shall be a matter of agreement between
the manufacturer and purchaser.
3 Heat Treatment:
3. 1 All pipe of grades shown in Table 1 except P5c, P23 P91, P92, P122, and P911 as provided in 5.3.2, shall be reheated and furnished in the full-annealed, isothermal annealed, or normalized and tempered condition. If furnished in the normalized and tempered condition, the minimum tempering temperature for Grades P5, P5b, P9, P21, and P22 shall be
1250°F [675°C], the minimum tempering temperature for Grades P1, P2, P11, P12, and P 15 shall be 1200°F [650°C].
Product show:
