Product Details:
Payment & Shipping Terms:
|
| Material: | Stainless Steel Forged Socket Welding Pipe Flange | Standard: | ASME B16.5 |
|---|---|---|---|
| Type: | FF | Technique: | Forging |
| Size: | 3" | Name: | Socket Welding Flange |
| High Light: | slip on pipe flanges,stainless steel pipe flange fittings |
||
stainless steel forged socket welding pipe flange ASME B16.5 RAISED FACE(S) WITH FINISH TO MSS SP6
Socket Weld Flange
A Socket Weld Flange is similar to slip on flanges,however, socket welds have
an internal recess on the inside diameter to allow for a smoother flow of the
process fluid. The positive of this is that is creates a smooth bore with the
proper welding and grinding. The negative of this type of flange is that it can
be more expensive than a slip-on due to more intricate machining, and they can be less readily available than slip-ons due to the fact that the
bottom half of the inside diameter must be made to the same schedule as the pipe that is being used (you must specify the schedule needed)
These socket weld flanges were initially developed for use on smaller sizes
of pipe at higher pressure ratings.
Product Type:
Weld Neck Flange, Slip On Flange, Socket Welding Flange, Lap Joint Flange, Threaded Flange
Blind Flange/Blind, Orifice Flange, Integral Pipe Flange, Reducing Flange, Pad Type Flange,
Loose Hubbed Flange, Welding Plate Flange, Weldoflange, Nipoflange, Welding Neck Collar,
Welding-on Collar
And we have ASME B16.5 SS 304 Forged Flanges, Blind Flange Distributor, ANSI B16.5 SS 304 Plate Flanges, SS 304 Plate Flange Dealer, ASME SA182 SS 304 Orifice Flanges, Stainless Steel 304 Threaded Flange
PP bag or soft white paper for individual packing,then put into wooden case or carton,Pallet
is available if customer request.
| Socket Weld Flange | A Socket Weld Flange is similar to slip on flanges,however, socket welds have |
| an internal recess on the inside diameter to allow for a smoother flow of the | |
| process fluid. The positive of this is that is creates a smooth bore with the | |
| proper welding and grinding. The negative of this type of flange is that it can | |
| be more expensive than a slip-on due to more intricate machining, and they can be less readily available than slip-ons due to the fact that the | |
| bottom half of the inside diameter must be made to the same schedule as the pipe that is being used (you must specify the schedule needed) | |
| These socket weld flanges were initially developed for use on smaller sizes | |
| of pipe at higher pressure ratings. | |
| Size | Plate flange:1/4"-160" |
| DN8-DN4000 | |
| Pressure | America Series:Class 150 ,Class 300, Class 600, Class 900A , |
| Class 1500,Class 2500. | |
| Europe Series:PN2.5,PN6,PN10,PN16,PN25,PN40,PN63,PN100, | |
| PN160,PN250,PN320,PN400. | |
| Flange Facing Types | America Series:Flat face(FF),Raised face(RF),Tongue(T),Groove(G), |
| Female(F),Male(M),Ring type joints face(RJ/RTJ) | |
| Europe Series:Type A(Flat Face),Type B(Raised Face),Type | |
| C(Tongue),Type D(Groove),Type E(Spigot),Type F(Recess),Type G(O-Ring Spigot),Type H(O-Ring Groove) | |
| Material | Carbon steel: ASTM A105,ASTM A105N,GB 20,C22.8. |
| Alloy steel: ASTM/ASME A234 WP 1-WP 12-WP 11-WP 22-WP 5-WP 91-WP 911 | |
| Stainless steel: ASTM/ASME A403 WP 304-304L-304H-304LN-304N | |
| ASTM/ASME A403 WP 316-316L-316H-316LN-316N-316Ti | |
| ASTM/ASME A403 WP 321-321H ASTM/ASME A403 WP 347-347H | |
| Low temperature steel: ASTM/ASME A402 WPL 3-WPL 6 | |
| High performance steel: ASTM/ASME A860 WPHY 42-46-52-60-65-70 | |
| Standards | ASME ANSI B16.5,ASME ANSI B16.47. |
| API 605,API 6L. | |
| MSS SP 44 | |
| CSA Z245.12 | |
| EN1092-1,EN1759-1. | |
| DIN2573,DIN2576. | |
| BS1560,BS 4504,BS 10. | |
| AFNOR NF E29-200-1 | |
| ISO7005-1 | |
| AS2129 | |
| JIS B2220 | |
| UNI 2276. UNI 2277.UNI 2278 .UNI 6089 .UNI 6090 | |
| Industrial Processes | Die forging,Machining |
